| Product characteristics |
|
| Number of inputs and outputs |
Number of digital outputs: 1 |
| Process connection |
threaded connection G 3/4 Internal thread |
| Application |
|
| Media |
Liquids; water; glycol solutions; Coolants |
| Medium temperature |
0...85 |
| Pressure rating |
<table><tr><td>25 bar</td><td>2.5 MPa</td></tr></table> |
| Electrical data |
|
| Operating voltage |
10...30 DC; (to SELV/PELV) |
| Current consumption |
< 15 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Inputs / outputs |
|
| Number of inputs and outputs |
Number of digital outputs: 1 |
| Outputs |
|
| Total number of outputs |
1 |
| Output signal |
switching signal |
| Electrical design |
PNP |
| Number of digital outputs |
1 |
| Output function |
normally open |
| Max. voltage drop switching output DC |
2.5 |
| Permanent current rating of switching output DC |
100 |
| Short-circuit protection |
yes |
| Overload protection |
yes |
| Measuring/setting range |
|
| Setting range |
5...100 |
| Accuracy / deviations |
|
| Repeatability |
1 |
| Hysteresis |
3...6 |
| Measuring error |
± 5 |
| Reaction times |
|
| Response time |
< 0.01 |
| Operating conditions |
|
| Ambient temperature |
0...60 |
| Storage temperature |
-15...80 |
| Protection |
IP 65; IP 67 |
| Tests / approvals |
|
| EMC |
<table><tr><td>DIN EN 61000-6-2</td><td></td></tr><tr><td>DIN EN 61000-6-3</td><td></td></tr></table> |
| Shock resistance |
<table><tr><td>DIN EN 60068-2-27</td><td>20 g (11 ms)</td></tr></table> |
| Vibration resistance |
<table><tr><td>DIN EN 60068-2-6</td><td>5 g (10...2000 Hz)</td></tr></table> |
| MTTF |
3318 |
| Mechanical data |
|
| Weight |
1282.7 |
| Material |
brass chemically nickel-plated; PPS; aluminum anodized; PA |
| Materials (wetted parts) |
stainless steel (1.4310 / 301); stainless steel (1.4301 / 304); PBT; brass chemically nickel-plated; PP; PPS; Polyolefin; O-ring: FKM |
| Process connection |
threaded connection G 3/4 Internal thread |
| Switching cycles mechanical |
10 million |
| Displays / operating elements |
|
| Display |
<table><tr><td>Switching status</td><td>4 x LED, yellow</td></tr></table> |
| Accessories |
|
| Items supplied |
<table><tr><td>Allen key</td></tr></table> |
| Remarks |
|
| Remarks |
<table><tr><td>Caution Do not turn the cap beyond the maximum value of the setting range.</td></tr><tr><td> All data refer to water (20 °C).</td></tr></table> |
| Notes |
Please note the changed housing design! |
| Pack quantity |
1 pcs. |
| Electrical connection |
|
| Connection |
Connector: 1 x M12; coding: A |
