| Application |
Flow monitoring; Wire break monitoring |
| Operating voltage |
19...36 DC |
| Current consumption |
< 70 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Power-on delay time |
10 |
| Number of channels |
1 |
| Electrical design |
PNP |
| Max. voltage drop switching output DC |
2.5 |
| Permanent current rating of switching output DC |
250 |
| Switching function flow monitoring |
output switches when flow is present: ON for output function = normally open / OFF for output function = normally closed |
| Short-circuit protection |
yes |
| Overload protection |
yes |
| Adjustment of the switch point |
pushbuttons |
| Ambient temperature |
-20...60 |
| Protection |
IP 67; (with sensor attached) |
| EMC |
| EN 61000-4-2 ESD | 4 kV CD / 8 kV AD | | EN 61000-4-3 HF radiated | 10 V/m | | EN 61000-4-4 Burst | 2 kV | | EN 61000-4-6 HF conducted | 10 V |
|
| Shock resistance |
| DIN IEC 68-2-27 | 30 g (6 ms) |
|
| Vibration resistance |
| DIN IEC 68-2-6 | 5 g (55...2000 Hz) |
|
| MTTF |
342 |
| Weight |
225.5 |
| Housing |
tubular |
| Dimensions |
Ø 50 / L = 83 |
| Material |
stainless steel (1.4404 / 316L); stainless steel (1.4301 / 304); PC; PBT-GF20; EPDM/X; brass |
| Display |
| Function | LED, bar graph | | Switching status | LED, orange flash in case of wire break |
|
| Remarks |
| connection for flow sensor without short-circuit protection / reverse polarity protection | | The flow sensor must be directly connected to the control monitor. | | A connection by means of extension cables is not allowed. |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; coding: A |
