| Application |
Flow monitoring |
| Media |
Liquids |
| Operating voltage tolerance |
-10...10 |
| Operating voltage |
24 DC |
| Current consumption |
< 45 |
| Reverse polarity protection |
yes |
| Power-on delay time |
< 20 |
| Number of channels |
1 |
| Electrical design |
PNP |
| Permanent current rating of switching output DC |
400 |
| Switching function flow monitoring |
output switches ON when flow is present |
| Switching function wire break monitoring |
output switches OFF in case of wire break |
| Short-circuit protection |
yes |
| Type of short-circuit protection |
yes (non-latching) |
| Overload protection |
yes |
| Adjustment of the switch point |
potentiometer |
| Ambient temperature |
0...60 |
| Protection |
IP 50 |
| Protection rating terminals |
IP 20 |
| MTTF |
624 |
| Weight |
142.5 |
| Housing |
rectangular |
| Type of mounting |
Mounting on DIN rail; (TH35 (EN 60715)) |
| Dimensions |
78 x 22.5 x 100 |
| Material |
plastics |
| Display |
|
| Pack quantity |
1 pcs. |
| Connection |
terminals: 12 x ...2.5 mm² |
