| Process connection |
threaded connection G 1/2 external thread |
| Media |
Liquids; Gases |
| Medium temperature |
-20...70 |
| Pressure rating |
|
| Response time |
1...10 |
| Response time |
1...10 |
| Connection to control monitor |
VS4000 |
| Max. temperature gradient of medium |
30 |
| Response time |
1...10 |
| Ambient temperature |
-20...70 |
| Protection |
IP 65; IP 67 |
| Approval |
CSANe 21ATEX2239; IECEx CSA 21.0045 |
| ATEX marking |
II 2G Ex ia IIC T4 Gb |
| Shock resistance |
| DIN IEC 68-2-27 | 40 g (11 ms) |
|
| Vibration resistance |
| DIN IEC 68-2-6 | 10 g (55...2000 Hz) |
|
| MTTF |
8519 |
| Weight |
367.5 |
| Housing |
tubular |
| Material |
stainless steel (1.4404 / 316L) |
| Materials (wetted parts) |
stainless steel (1.4404 / 316L) |
| Process connection |
threaded connection G 1/2 external thread |
| Remarks |
| In principle, the type test according to 2014/34/EU (ATEX) only takes atmospheric conditions into account (0.8...1.1 bar). | | For pressures outside this range use must be assessed and approved by the user. | | Adhere to the operating instructions and the type test certificate. |
|
| Pack quantity |
1 pcs. |
| Connection |
Cable: 6 m, TPE-S; Maximum cable length: 100 m; (4 x 0.5 mm²); 4 x 0.34 mm² |
