| Probe length L |
15...107 |
| Process connection |
Clamp fitting Ø 10 mm |
| System |
gold-plated contacts |
| Application |
high temperature |
| Installation |
Sensor suitable for clamp fitting |
| Media |
Liquids; Gases |
| Medium temperature |
-25...80 |
| Pressure rating |
|
| Response time |
1...10 |
| Response time |
1...10 |
| Connection to control monitor |
VS3000 |
| Probe length L |
15...107 |
| Max. temperature gradient of medium |
30 |
| Response time |
1...10 |
| Storage temperature |
-25...80 |
| Protection |
IP 67 |
| Shock resistance |
| DIN IEC 68-2-27 | 40 g (11 ms) |
|
| Vibration resistance |
| DIN IEC 68-2-6 | 10 g (55...2000 Hz) |
|
| MTTF |
8393.77 |
| Weight |
62.5 |
| Housing |
tubular |
| Dimensions |
Ø 10 / L = 132 |
| Material |
stainless steel (1.4404 / 316L) several parts, welded |
| Materials (wetted parts) |
stainless steel (1.4404 / 316L) several parts, welded |
| Process connection |
Clamp fitting Ø 10 mm |
| Probe diameter |
7.7 |
| Accessories (optional) |
| Clamp adapter: R 1/2, E40160 | | Clamp adapter: 1/2" NPT, E40174 |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; coding: A; Contacts: gold-plated; Maximum cable length: 100 m |
