| Probe length L |
243 |
| Process connection |
threaded connection M18 x 1,5 Internal thread |
| Media |
Liquids; Gases; aggressive media |
| Medium temperature |
-25...80 |
| Pressure rating |
|
| Connection to control monitor |
VS3000 |
| Probe length L |
243 |
| Setting range |
3...300 |
| Greatest sensitivity |
3...60 |
| Setting range |
200...3000 |
| Greatest sensitivity |
200...800 |
| Max. temperature gradient of medium |
300 |
| Response time |
1...10 |
| Storage temperature |
-25...80 |
| Protection |
IP 67 |
| Shock resistance |
| DIN IEC 68-2-27 | 50 g (11 ms) |
|
| Vibration resistance |
| DIN IEC 68-2-6 | 10 g (55...2000 Hz) |
|
| MTTF |
8393.77 |
| Weight |
95 |
| Housing |
tubular |
| Dimensions |
Ø 8.2 / L = 282 |
| Material |
titanium (3.7035); EPDM; ULTEM |
| Materials (wetted parts) |
titanium (3.7035); O-ring: FKM 80 Shore A |
| Process connection |
threaded connection M18 x 1,5 Internal thread |
| Probe diameter |
8.2 |
| Installation length EL |
243 |
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; coding: A; Maximum cable length: 100 m |
