| Product characteristics |
|
| Probe length L |
143 |
| Process connection |
threaded connection M18 x 1,5 Internal thread |
| Application |
|
| Media |
Liquids; Gases; aggressive media |
| Medium temperature |
-25...80 |
| Pressure rating |
<table><tr><td>100 bar</td><td>10 MPa</td></tr></table> |
| Electrical data |
|
| Connection to control monitor |
VS3000 |
| Measuring/setting range |
|
| Probe length L |
143 |
| Liquids |
|
| Setting range |
3...300 |
| Greatest sensitivity |
3...60 |
| Gases |
|
| Setting range |
200...3000 |
| Greatest sensitivity |
200...800 |
| Accuracy / deviations |
|
| Max. temperature gradient of medium |
300 |
| Reaction times |
|
| Response time |
1...10 |
| Operating conditions |
|
| Storage temperature |
-25...80 |
| Protection |
IP 67 |
| Tests / approvals |
|
| Shock resistance |
<table><tr><td>DIN IEC 68-2-27</td><td>50 g (11 ms)</td></tr></table> |
| Vibration resistance |
<table><tr><td>DIN IEC 68-2-6</td><td>10 g (55...2000 Hz)</td></tr></table> |
| MTTF |
8393.77 |
| Mechanical data |
|
| Weight |
75 |
| Housing |
tubular |
| Dimensions |
Ø 8.2 / L = 182 |
| Material |
titanium (3.7035); EPDM; ULTEM |
| Materials (wetted parts) |
titanium (3.7035); O-ring: FKM 80 Shore A |
| Process connection |
threaded connection M18 x 1,5 Internal thread |
| Probe diameter |
8.2 |
| Installation length EL |
143 |
| Remarks |
|
| Pack quantity |
1 pcs. |
| Electrical connection |
|
| Connection |
Connector: 1 x M12; coding: A; Maximum cable length: 100 m |
