| Probe length L |
30 |
| Process connection |
threaded connection G 1/2 external thread |
| Media |
Liquids; aggressive media |
| Medium temperature |
5...70 |
| Pressure rating |
|
| Response time |
2...20 |
| Connection to control monitor |
VS3000 |
| Probe length L |
30 |
| Max. temperature gradient of medium |
7 |
| Response time |
2...20 |
| Protection |
IP 67 |
| Shock resistance |
| DIN IEC 68-2-27 | 40 g (11 ms) |
|
| Vibration resistance |
| DIN IEC 68-2-6 | 10 g (55...2000 Hz) |
|
| MTTF |
8213 |
| Weight |
55 |
| Housing |
tubular |
| Material |
ceramics (99.7 % Al2O3) |
| Materials (wetted parts) |
ceramics (99.7 % Al2O3) |
| Process connection |
threaded connection G 1/2 external thread |
| Probe diameter |
8.6 |
| Installation length EL |
45 |
| Items supplied |
|
| Remarks |
| For sealing use the supplied PTFE packing washer. |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; coding: A; Maximum cable length: 100 m |
