| Probe length L |
42 |
| Process connection |
Clamp DN25...DN40 (1...1,5") DIN 32676 (ISO 2852) |
| Application |
high temperature; hygienic applications |
| Pressure rating |
|
| Response time |
1...10 |
| Response time |
1...10 |
| Connection to control monitor |
VS3000 |
| Probe length L |
42 |
| Max. temperature gradient of medium |
15 |
| Response time |
1...10 |
| Protection |
IP 67 |
| Shock resistance |
| DIN IEC 68-2-27 | 40 g (11 ms) |
|
| Vibration resistance |
| DIN IEC 68-2-6 | 10 g (55...2000 Hz) |
|
| MTTF |
8648 |
| Weight |
485 |
| Housing |
tubular |
| Dimensions |
Ø 14 / L = 64 |
| Material |
stainless steel (1.4571/316Ti ) |
| Materials (wetted parts) |
stainless steel (1.4571/316Ti ) |
| Process connection |
Clamp DN25...DN40 (1...1,5") DIN 32676 (ISO 2852) |
| Probe diameter |
7.7 |
| Installation length EL |
42 |
| Remarks |
| The 3-A qualification is only valid if adapters with 3-A qualification are used for installation. |
|
| Pack quantity |
1 pcs. |
| Connection |
Cable: 6 m, silicone; Maximum cable length: 100 m; 5 x 0.34 mm² |
