| Number of inputs and outputs |
Number of analog outputs: 1 |
| Process connection |
Clamp fitting Ø 23 mm |
| Medium temperature |
20...40 |
| Pressure rating |
|
| Operating voltage tolerance |
-10...10 |
| Operating voltage |
24 DC |
| Current consumption |
< 35 |
| Min. insulation resistance |
100; (500 V DC) |
| Power-on delay time |
90 |
| Number of inputs and outputs |
Number of analog outputs: 1 |
| Total number of outputs |
1 |
| Output signal |
analog signal |
| Number of analog outputs |
1 |
| Analog voltage output |
0...10 |
| Flow range |
200...3000 |
| Note on flow range |
|
| Max. temperature gradient of medium |
1 |
| Ambient temperature |
-10...40 |
| Storage temperature |
-25...85 |
| Protection |
IP 65 |
| MTTF |
727 |
| Weight |
195 |
| Housing |
tubular |
| Dimensions |
Ø 23 / L = 142 |
| Material |
housing: PBT; sensor surface: titanium |
| Materials (wetted parts) |
PBT; titanium |
| Process connection |
Clamp fitting Ø 23 mm |
| Display |
|
| Items supplied |
| Mounting clamp: 1, E40048 |
|
| Pack quantity |
1 pcs. |
| Connection |
Cable: 2 m, PUR; 4 x 0.5 mm², PVC |
