| Electrical design |
NPN |
| Output function |
normally open |
| Dimensions |
17.5 x 2.8 x 7.7 |
| Operating voltage |
10...30 DC |
| Current consumption |
< 10 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Max. power-on delay time |
30 |
| Electrical design |
NPN |
| Output function |
normally open |
| Max. voltage drop switching output DC |
2.5 |
| Permanent current rating of switching output DC |
100 |
| Switching frequency DC |
10000 |
| Short-circuit protection |
yes |
| Overload protection |
yes |
| Magnetic sensitivity |
2.8 |
| Travel speed |
> 10 |
| Hysteresis |
1.5 |
| Repeatability |
< 0.2 |
| Ambient temperature |
-25...85 |
| Protection |
IP 65; IP 67 |
| EMC |
| EN 61000-4-2 ESD | - CD / 8 kV AD | | EN 61000-4-3 HF radiated | 10 V/m | | EN 61000-4-4 Burst | 2 kV | | EN 61000-4-6 HF conducted | 10 V | | EN 55011 | class B |
|
| Weight |
21.2 |
| Mounting |
non-flush mountable |
| Cylinder type |
C-slot cylinders |
| Dimensions |
17.5 x 2.8 x 7.7 |
| Material |
housing: PA; Fastening clamp: stainless steel; protective tube: PTFE |
| Display |
| Switching status | 1 x LED, yellow |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: M12; coding: A; Locking: Knurled nut, rotatable |
