| Electrical design |
PNP |
| Output function |
normally open |
| Dimensions |
26.1 x 2.8 x 5.5 |
| Operating voltage |
10...30 DC; (cULus - Class 2 source required) |
| Current consumption |
< 10 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Max. power-on delay time |
30 |
| Electrical design |
PNP |
| Output function |
normally open |
| Max. voltage drop switching output DC |
2.5 |
| Permanent current rating of switching output DC |
100 |
| Switching frequency DC |
5000 |
| Short-circuit protection |
yes |
| Overload protection |
yes |
| Magnetic sensitivity |
2 |
| Travel speed |
> 10 |
| Hysteresis |
1 |
| Repeatability |
< 0.2 |
| Ambient temperature |
-25...85 |
| Protection |
IP 65; IP 67 |
| EMC |
| EN 61000-4-2 ESD | - CD / 8 kV AD | | EN 61000-4-3 HF radiated | 10 V/m | | EN 61000-4-4 Burst | 2 kV | | EN 61000-4-6 HF conducted | 10 V | | EN 55011 | class B |
|
| MTTF |
2064 |
| UL approval |
|
| Weight |
18.4 |
| Mounting |
flush mountable |
| Cylinder type |
C-slot cylinders |
| Dimensions |
26.1 x 2.8 x 5.5 |
| Material |
housing: PA; Fastening clamp: stainless steel |
| Tightening torque |
< 0.24 |
| Display |
| Switching status | 1 x LED, yellow |
|
| Pack quantity |
1 pcs. |
| Connection |
Cable: 2 m, PUR; 3 x 0.08 mm² |
