| Electrical design |
PNP |
| Output function |
normally open |
| Housing |
tubular |
| Dimensions |
Ø 97 / L = 11 |
| Principle of operation |
dynamic |
| Operating voltage |
12...30 DC |
| Current consumption |
30 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Max. power-on delay time |
500 |
| Electrical design |
PNP |
| Output function |
normally open |
| Permanent current rating of switching output DC |
200 |
| Short-circuit protection |
yes |
| Overload protection |
yes |
| Length of output signal |
300 |
| Response time |
35 |
| Ambient temperature |
-40...85 |
| Protection |
IP 67; IP 69K; (on the front) |
| Weight |
136.5 |
| Housing |
tubular |
| Dimensions |
Ø 97 / L = 11 |
| Material |
actuating surface: PA Grilamid TR 90UV transparent; housing: PC/ABS black |
| Display |
| Switching status | 8 x LED, red | | Function | 8 x LED, green can be activated via PIN 2 |
|
| Accessories (optional) |
| surround in different colors |
|
| Pack quantity |
1 pcs. |
|
Cable: 0.3 m, PUR |
| Connection |
Connector: 1 x M12; coding: A |
