| Electrical design |
PNP |
| Output function |
normally open / closed; (selectable) |
| Sensing range |
Programmable sensing range |
| Housing |
Threaded type |
| Dimensions |
M30 x 1.5 / L = 116 |
| Media |
dry bulk material |
| Recommended media |
plastic granulates |
| Operating voltage |
10...30 DC |
| Current consumption |
34; (typical: 34 (24 V); maximum: 39 (30 V)) |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Measuring principle |
capacitive |
| Electrical design |
PNP |
| Output function |
normally open / closed; (selectable) |
| Max. voltage drop switching output DC |
2.5 |
| Max. voltage drop of function check output |
3.5 |
| Max. current load for function check output |
10 |
| Permanent current rating of switching output DC |
200 |
| Switching frequency DC |
10 |
| Short-circuit protection |
yes |
| Type of short-circuit protection |
yes (non-latching) |
| Overload protection |
yes |
| Sensing range |
Programmable sensing range |
| Sensing range adjustable |
yes |
| Ambient temperature |
-15...230 |
| Note on ambient temperature |
| sensor: -15...230 °C | | briefly: ...250 °C (4 h) | | HF connection cable: -25...200 °C | | electronics: -25...70 °C |
|
| Protection |
IP 67 |
| EMC |
|
| MTTF |
347 |
| Weight |
458.5 |
| Housing |
Threaded type |
| Mounting |
non-flush mountable |
| Dimensions |
M30 x 1.5 / L = 116 |
| Thread designation |
M30 x 1.5 |
| Material |
housing sensor: PPS; brass white bronze coated; housing electronic: PBT; PP; brass white bronze coated |
| Display |
| Switching status | 2 x LED, yellow | | Power | 1 x LED, green | | error | 1 x LED, red |
|
| Items supplied |
|
| Pack quantity |
1 pcs. |
|
Cable: 2 m |
|
Connector: 1 x M12; coding: A |
