| Electrical design |
PNP |
| Output function |
normally open / closed; (selectable) |
| Sensing range |
60 |
| Housing |
rectangular |
| Dimensions |
105 x 80 x 40 |
| Operating voltage |
10...36 DC |
| Current consumption |
5; (24 V) |
| Protection class |
II |
| Reverse polarity protection |
yes |
| Electrical design |
PNP |
| Output function |
normally open / closed; (selectable) |
| Max. voltage drop switching output DC |
2.5 |
| Permanent current rating of switching output DC |
250 |
| Switching frequency DC |
10 |
| Short-circuit proof |
yes |
| Overload protection |
yes |
| Sensing range |
60 |
| Real sensing range Sr |
60 ± 10 % |
| Operating distance |
0...48.6 |
| Correction factor |
glass: 0.4 / water: 1 / ceramics: 0.2 / PVC: 0.2 |
| Hysteresis |
1...15 |
| Switch-point drift |
-15...15 |
| Ambient temperature |
-25...80 |
| Protection |
IP 65 |
| EMC |
|
| MTTF |
537 |
| Weight |
309.5 |
| Housing |
rectangular |
| Mounting |
non-flush mountable |
| Dimensions |
105 x 80 x 40 |
| Material |
PPE modified |
| Display |
| Switching status | 1 x LED, yellow |
|
| Items supplied |
| spring washers: 4 | | cylinder screws: 4 |
|
| Pack quantity |
1 pcs. |
|
Connector: 1 x M12; coding: A |
