| Electrical design |
PNP |
| Output function |
normally open |
| Sensing range |
2.5...8 |
| Housing |
Threaded type |
| Dimensions |
M18 x 1 / L = 123 |
| Operating voltage |
10...36 DC |
| Protection class |
II |
| Reverse polarity protection |
yes |
| Electrical design |
PNP |
| Output function |
normally open |
| Max. voltage drop switching output DC |
2.5 |
| Permanent current rating of switching output DC |
400 |
| Switching frequency DC |
50 |
| Short-circuit proof |
yes |
| Overload protection |
yes |
| Sensing range |
2.5...8 |
| Sensing range adjustable |
yes |
| Factory setting sensing range |
8 |
| Real sensing range Sr |
8 ± 10 % |
| Operating distance |
0...6.5 |
| Correction factor |
glass: 0.4 / water: 1 / ceramics: 0.2 / PVC: 0.2 |
| Hysteresis |
3...15 |
| Switch-point drift |
-15...15 |
| Ambient temperature |
-25...80 |
| Protection |
IP 65 |
| Weight |
72.575 |
| Housing |
Threaded type |
| Mounting |
non-flush mountable |
| Dimensions |
M18 x 1 / L = 123 |
| Thread designation |
M18 x 1 |
| Material |
PBT |
| Display |
| Switching status | 1 x LED, red |
|
| Items supplied |
| lock nuts: 2 | | screwdriver: 1 |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; coding: A |
