| Number of inputs and outputs |
Number of analog outputs: 2 |
| Process connection |
threaded connection G 1/2 |
| System |
gold-plated contacts |
| Media |
mineral oils; synthetic esters; biodegradable oils |
| Cannot be used for |
See operating instructions, chapter "Intended use". |
| Medium temperature |
-40...120 |
| Pressure rating |
|
| Vacuum resistance |
-1000 |
| Operating voltage |
9...33 DC |
| Current consumption |
< 50 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Power-on delay time |
2 |
| Max. current load total |
0.085 |
| Number of inputs and outputs |
Number of analog outputs: 2 |
| Total number of outputs |
2 |
| Output signal |
analog signal |
| Output function |
analog output humidity / temperature |
| Number of analog outputs |
2 |
| Analog current output |
4...20 |
| Max. load |
(UB - 5V) * 50 |
| Measuring range |
0...100 |
| Response time |
oil: T09 < 30 |
| Accuracy |
± 3%; ( ± 5 % in the range < 10 %, > 90 %) |
| Repeatability |
± 0,5 % |
| Resolution |
12 Bit |
| Response time |
oil: T09 < 30 |
| Ambient temperature |
-40...85 |
| Storage temperature |
-40...85 |
| Max. relative air humidity |
100 |
| Protection |
IP 68; IP 69K; (7 days / 3 m water depth / 0.3 bar: IP 68) |
| EMC |
| DIN EN 61000-6-2 | | | DIN EN 61000-6-4 | |
|
| Shock resistance |
| DIN EN 60068-2-27 | 50 g (11 ms) |
|
| Vibration resistance |
| DIN EN 60068-2-6 | 20 g (10...2000 Hz) |
|
| MTTF |
284 |
| UL approval |
|
| Pressure equipment directive |
sound engineering practice; can be used for group 2 fluids; group 1 fluids on request |
| Weight |
118.5 |
| Material |
stainless steel (1.4404 / 316L); PEI; sealing: FKM |
| Materials (wetted parts) |
stainless steel (1.4404 / 316L); PA6 GF50; epoxy resin; sealing: NBR |
| Process connection |
threaded connection G 1/2 |
| Remarks |
| Accuracy values expressed in percent refer to the measuring span |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12 (EN 61067-2-101); coding: A; Contacts: gold-plated |
