| Number of inputs and outputs |
Number of analog outputs: 1 |
| Process connection |
threaded connection G 1 1/2 Internal thread |
| System |
gold-plated contacts |
| Media |
Conductive liquids |
| Note on media |
|
| Cannot be used for |
See the operating instructions, chapter "Function and features". |
| Medium temperature |
-5...60 |
| Pressure rating |
|
| Note on pressure rating |
| at medium temperature 20°C |
|
| Vacuum resistance |
|
| Operating voltage |
18...30 DC |
| Current consumption |
< 100 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Power-on delay time |
2 |
| Measuring principle |
inductive |
| Number of inputs and outputs |
Number of analog outputs: 1 |
| Total number of outputs |
1 |
| Output signal |
analog signal; IO-Link |
| Output function |
selectable conductivity / temperature / NaCl concentration |
| Number of analog outputs |
1 |
| Analog current output |
4...20; (scalable) |
| Max. load |
500 |
| Accuracy |
| (0...4 %) pure water | 0,1 | | (4...14 %) pure water | 0,4 | | (14...25 %) pure water | 1 | | (0...12 %) water with conductivity 1000 µS/cm | 0,4 |
|
| Resolution |
0,1 |
| Response time |
< 2; (T09; Damping = 0); for conductance values <1000 µS/cm < 5s; ( T09; Damping = 0) |
| Response time |
< 120; (T09) |
| Communication interface |
IO-Link |
| Transmission type |
COM2 (38,4 kBaud) |
| IO-Link revision |
1.1 |
| SDCI standard |
IEC 61131-9 |
| Profiles |
| Smart Sensor - SSP 4.3.2 | Measuring and Switching Sensor, floating point, 2 channel | | Common - I&D | Identification and Diagnosis | | Extension | Quantity detection, switches when value exceeds the setpoint | | Function | ProductURI |
|
| SIO mode |
no |
| Required master port class |
A |
| Process data analog |
1 |
| Min. process cycle time |
6.4 |
| IO-Link process data (cyclical) |
| Function | bit length |
|---|
| conductivity | 32 | | temperature | 32 | | status | 4 | | binary switching information | 4 |
|
| IO-Link functions (acyclical) |
NaCl concentration; memory; operating hours counter; internal temperature; simulation function |
| Supported DeviceIDs |
| Type of operation | DeviceID |
|---|
| default | 1593 |
|
| Ambient temperature |
-25...50 |
| Storage temperature |
-25...75 |
| Protection |
IP 68; IP 69K; (7 days / 3 m water depth / 0.3 bar: IP 68) |
| EMC |
| DIN EN 61326-1 | group 1: class B |
|
| Shock resistance |
| DIN EN 60068-2-27 | 50 g (11 ms) |
|
| Vibration resistance |
| DIN EN 60068-2-6 | 20 g (10...2000 Hz) |
|
| MTTF |
127 |
| UL approval |
|
| Weight |
404.4 |
| Material |
housing: PP fiber-reinforced; knurled nut: PP fiber-reinforced |
| Materials (wetted parts) |
housing: PP fiber-reinforced; knurled nut: PP fiber-reinforced; O-ring: EPDM |
| Process connection |
threaded connection G 1 1/2 Internal thread |
| Surface characteristics Ra/Rz of the wetted parts |
Ra < 0.8 µm |
| Remarks |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12 (EN 61067-2-101); coding: A; Contacts: gold-plated |
