| Number of inputs and outputs |
Number of analog outputs: 1 |
| Process connection |
threaded connection G 1 external thread sealing cone |
| System |
gold-plated contacts |
| Media |
Conductive liquids |
| Note on media |
|
| Cannot be used for |
See the operating instructions, chapter "Function and features". |
| Medium temperature |
-25...100; (< 1 h: 150) |
| Pressure rating |
|
| Vacuum resistance |
|
| Operating voltage |
18...30 DC |
| Current consumption |
< 100 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Power-on delay time |
2 |
| Measuring principle |
inductive |
| Number of inputs and outputs |
Number of analog outputs: 1 |
| Total number of outputs |
1 |
| Output signal |
analog signal; IO-Link |
| Output function |
analog output scalable; selectable conductivity / temperature |
| Number of analog outputs |
1 |
| Analog current output |
4...20 |
| Max. load |
500 |
| Response time |
< 2; (T09; Damping = 0) |
| Response time |
< 25; (T09) |
| Communication interface |
IO-Link |
| Transmission type |
COM2 (38,4 kBaud) |
| IO-Link revision |
1.1 |
| SDCI standard |
IEC 61131-9 |
| Profiles |
| Smart Sensor - SSP 3.1 | Measuring Sensor | | Common - I&D | Identification and Diagnosis |
|
| SIO mode |
no |
| Required master port class |
A |
| Process data analog |
1 |
| Min. process cycle time |
6.4 |
| Supported DeviceIDs |
| Type of operation | DeviceID |
|---|
| default | 922 |
|
| Ambient temperature |
-40...60 |
| Storage temperature |
-40...85 |
| Protection |
IP 68; IP 69K; (7 days / 3 m water depth / 0.3 bar: IP 68) |
| EMC |
| DIN EN 61000-6-2 | | | DIN EN 61000-6-3 | in a closed metal tank |
|
| Shock resistance |
| DIN EN 60068-2-27 | 50 g (11 ms) |
|
| Vibration resistance |
| DIN EN 60068-2-6 | 20 g (10...2000 Hz) |
|
| UL approval |
|
| Weight |
736.5 |
| Material |
stainless steel (1.4404 / 316L); PEEK; PEI; FKM |
| Materials (wetted parts) |
PEEK |
| Process connection |
threaded connection G 1 external thread sealing cone |
| Remarks |
| Attention: The unit must only be installed in a process connection for G1 sealing cone. | | The G1A sealing cone of the unit is only suited for adapters with metal end stop. | | MW = Measured value |
|
| Notes |
Digital meets analog: integrating modern IO-Link sensors the analog way. The EIO104 allows you to realize two analog signals from intelligent IO-Link sensors with several process values. |
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12 (EN 61067-2-101); coding: A; Contacts: gold-plated |
