| Application |
zone 21 hazardous area; zone 22 hazardous area; food industry |
| Operating voltage |
250 AC/DC |
| Rated insulation voltage |
500 |
| Electrical design |
snap-action contact; thermal current: 10 A |
| Output function |
| auxiliary contact | 2 x normally open | | safety contact | 2 x normally closed |
|
| Contact rating |
2,5 A |
| Short-circuit protection |
no |
| Ambient temperature |
-25...60 |
| Protection |
IP 67; IP 69K |
| Shock resistance |
|
| Vibration resistance |
| IEC62-2-6 | 10-55 Hz / +1 Hz |
|
| Weight |
3447.2 |
| Material |
housing: stainless steel (1.4401 / 316) |
| Information on service life |
| Switching cycles (mechanical): | > 1.000.000 |
|
| Mounting orientation |
any |
| Rope span |
125 m; (per side) |
| Activation force |
< 125; (tension force: 130 N) |
| Connection |
Cable: 3 m; Cable gland (stainless steel) |
| Remarks |
| For information about installation and operation please see the operating instructions. | | Ex-approved switch type LS-Ex: Ex d IIC T6 (-20 °C ≤ Ta ≤ 60 °C) Gb; Ex td IIIC T85 °C ( -20 °C ≤ Ta ≤ 60 °C) Db |
|
| Pack quantity |
1 pcs. |
