| Operating voltage |
110...240 AC / 5...24 DC |
| Rated insulation voltage |
500 |
| Electrical design |
snap-action contact; max. switching voltage: 240 V; switching capacity: 720 VA; thermal current: 10 A |
| Output function |
| auxiliary contact | 2 x normally open | | safety contact | 4 x NC |
|
| Minimum load current |
5; (5 V DC) |
| Contact rating |
3 A (240 V AC) / 6 A (120 V AC) / 2,5 A (24 V DC); (inductive load) |
| Short-circuit protection |
no |
| Ambient temperature |
-25...80 |
| Protection |
IP 67 |
| Shock resistance |
|
| Vibration resistance |
|
| Weight |
1498.5 |
| Material |
housing: diecast aluminium yellow; switching contact: silver-plated |
| Information on service life |
| Switching cycles (mechanical): | > 1.000.000 |
|
| Mounting orientation |
any |
| Rope span |
125 m; (per side) |
| Activation force |
< 125; (tension force: 130 N) |
| Connection |
terminals: ...2.5 mm² |
| Remarks |
| For information about installation and operation please see the operating instructions. |
|
| Pack quantity |
1 pcs. |
