| Operating voltage |
8...32 DC |
| Current consumption |
< 400 |
| Reverse polarity protection |
yes |
| Total number of inputs and outputs |
124 |
| Number of inputs and outputs |
Number of digital inputs: 68; Number of analog inputs: 24; Number of frequency inputs: 16; Number of resistor inputs: 4; Number of digital outputs: 54; Number of analog outputs: 2; Number of outputs with H-bridge: 6 |
| Number of frequency inputs |
16 |
| Number of resistor inputs |
4 |
| Number of digital inputs |
68 |
| Number of analog inputs |
24 |
| Analog input (current) |
0...20 |
| Analog input (voltage) |
0...32 |
| Number of digital outputs |
54 |
| Number of analog outputs |
2 |
| Analog voltage output |
0...10 |
| Short-circuit protection |
yes |
| Number of PWM outputs |
54 |
| Number of PWM-I outputs |
36 |
| Number of outputs with H-bridge |
6 |
| Parameter setting options |
input/output functions |
| PLC function to IEC 61131-3 |
yes |
| Number of CAN interfaces |
4 |
| Number of Ethernet interfaces |
1 |
| Number of R232 interfaces |
1 |
| Storage temperature |
-40...85 |
| Protection |
IP 65; IP 67; (in conjunction with a corresponding connector) |
| Complies with the requirements |
| ISO 13849-1: 2015 PL d | | IEC 62061 SIL 2 |
|
| Weight |
1921.5 |
| Housing |
rectangular |
| Type of mounting |
screw mounting; (4 x M6) |
| Dimensions |
219 x 271 x 47 |
| Items supplied |
| Protective cap: M12 | | self-tapping screw: 1 x M4, for shield connection |
|
| Pack quantity |
1 pcs. |
