| Operating voltage |
8...32 DC |
| Total number of inputs and outputs |
80 |
| Number of inputs and outputs |
Number of digital inputs: 32; Number of analog inputs: 32; Number of frequency inputs: 32; Number of digital outputs: 48; Number of outputs with H-bridge: 4 |
| Number of frequency inputs |
32 |
| Number of digital inputs |
32 |
| Number of analog inputs |
32 |
| Analog input (current) |
0...20 |
| Analog input (voltage) |
0...32 |
| Number of digital outputs |
48 |
| Number of PWM outputs |
32 |
| Number of PWM-I outputs |
32 |
| Number of outputs with H-bridge |
4 |
| Parameter setting options |
input/output functions |
| PLC function to IEC 61131-3 |
yes |
| Number of CAN interfaces |
4 |
| Number of R232 interfaces |
1 |
| Number of USB interfaces |
1 |
| Standard |
| IEC 61508:2010 SIL 2 | | IEC 62061:2021 SIL 2 | | ISO 13849:2023 PL d |
|
| Weight |
2025.5 |
| Housing |
rectangular |
| Type of mounting |
screw mounting |
| Dimensions |
153 x 277 x 43 |
| Notes |
Please do not use for new projects. |
| Pack quantity |
1 pcs. |
