| Design | AS-i / 24 V | ||
| Application | sanitary and wet areas in the food industry | ||
| Protection class | III | ||
| Max. current load total | 8 | ||
| Electrical design | AS-i | ||
| Ambient temperature | -30...80 | ||
| Max. relative air humidity | 80; (31 °C; linearly decreasing to 50 % (40 °C)) | ||
| Max. height above sea level | 2000 | ||
| Protection | IP 67; IP 68; IP 69K | ||
| Degree of soiling | 2 | ||
| EMC |
|
||
| Weight | 101.5 | ||
| Material | metal parts: stainless steel (1.4404 / 316L); rubber gasket for contact pins: FPM; O-ring: EPDM | ||
| Tightening torque | 2.5; (lock nuts) | ||
| Accessories (optional) |
|
||
| Pack quantity | 1 pcs. |
Приемущества
| Reliable distribution of the AS-i voltage or the external 24 V supply |
| Hygienic design for the requirements of the food and beverage industry |
| Easy and quick connection due to insulation displacement technology |
| Resistant to high-pressure cleaning with aggressive cleaning agents |
| Wide operating temperature range and high protection rating |
