| Design | AS-i / 24 V | ||
| Operating voltage | 26.5...31.6 DC; (AS-i) | ||
| Protection class | III | ||
| Operating voltage AUX DC | 18...32 | ||
| Max. current load total | 4; (AS-i: 2 A; AUX: 2 A) | ||
| Ambient temperature | -30...80 | ||
| Max. relative air humidity | 80; (31 °C; linearly decreasing to 50 % (40 °C)) | ||
| Max. height above sea level | 2000 | ||
| Protection | IP 67; IP 68; IP 69K | ||
| Degree of soiling | 2 | ||
| EMC |
|
||
| Weight | 112.3 | ||
| Material | metal parts: stainless steel (1.4404 / 316L); rubber gasket for contact pins: FPM; O-ring: EPDM | ||
| Tightening torque | 2.5; (lock nuts) | ||
| Accessories (optional) |
|
||
| Pack quantity | 1 pcs. | ||
| Connection | Connector: 1 x M12; coding: A; Tightening torque: 1.2...1.4 Nm |
Приемущества
| for the transition of AS-i / AUX flat cable to M12 connector |
| Hygienic design for the requirements of the food and beverage industry |
| Easy and quick connection due to insulation displacement technology |
| Resistant to high-pressure cleaning with aggressive cleaning agents |
| Wide operating temperature range and high protection rating |
