| Application |
sanitary and wet areas in the food industry |
| Operating voltage |
26.5...31.6 DC |
| Max. current load per module/slot |
4; (AS-i: 4 A; AUX: 4 A) |
| Additional voltage supply |
20...30 DC; (AUX) |
| Ambient temperature |
-5...70 |
| Storage temperature |
-5...70 |
| Max. relative air humidity |
90; (non condensing) |
| Max. height above sea level |
2000 |
| Protection |
IP 68; IP 69K |
| Degree of soiling |
2 |
| EMC |
|
| Weight |
613.5 |
| Housing |
tubular |
| Type of mounting |
Mounting base |
| Dimensions |
Ø 137.3 / L = 80 |
| Material |
housing: stainless steel; O-ring: EPDM; Protective caps: PP |
| Sealing material |
EPDM |
| Module connection |
M12 |
| Items supplied |
| Protective cap: 8 x M12, E70297 |
|
| Accessories (optional) |
|
| Pack quantity |
1 pcs. |
|
Connector: 8 x M12; coding: A; sealing: EPDM; Tightening torque: 1.2...1.4 Nm; Maximum cable length: 20 m |
|
Connector: 1 x M12; coding: A; sealing: EPDM; Tightening torque: 1.2...1.4 Nm; Maximum cable length: 2 m |
