| Application |
field installation |
| Operating voltage |
26.5...31.6 DC |
| Max. current consumption from AS-i |
2000 |
| Max. current load total |
4 |
| Additional voltage supply |
20...30 DC; (AUX) |
| Max. current consumption from additional supply |
2000; (AUX) |
| Ambient temperature |
-25...80 |
| Storage temperature |
-25...80 |
| Max. relative air humidity |
90; (non condensing) |
| Max. height above sea level |
2000 |
| Protection |
IP 67; (when flat cables are used E7400x / E7401x) |
| EMC |
| EN 61000-6-2 | | | EN 62026-2 | | | EN 50581 | |
|
| UL approval |
|
| Weight |
272.5 |
| Housing |
rectangular |
| Type of mounting |
AS-i flat cable connection; Backplane mounting |
| Dimensions |
118.2 x 60 x 27 |
| Material |
PA 6.6; Socket: brass nickel-plated; threaded inserts in the lower part: brass nickel-plated; O-ring: FKM; Piercing contacts: CuSn6 nickel-plated and tin-plated |
|
Connector: M12; coding: A |
| Accessories (optional) |
| stainless steel sleeve, for installation in case of high mechanical stress , E70402 |
|
| Pack quantity |
1 pcs. |
