| Application |
for the distribution of the AS-i voltage or the external 24 V supply |
| Protection class |
III |
| Max. current load total |
8 |
| Electrical design |
AS-i |
| Ambient temperature |
0...60 |
| Note on ambient temperature |
| -15...60 °C: only in connection with an EPDM cable |
|
| Max. relative air humidity |
80; (31 °C; linearly decreasing to 50 % (40 °C)) |
| Max. height above sea level |
2000 |
| Protection |
IP 67; (when used outside the hazardous area: IP 68 / IP 69K) |
| Degree of soiling |
2 |
| ATEX marking |
II 3G Ex ec IIC T6 Gc X |
|
II 3D Ex tc IIIC T 70°C Dc X |
| Weight |
132.5 |
| Material |
metal parts: stainless steel (1.4404 / 316L); rubber gasket for contact pins: FKM; sealing: EPDM |
| Tightening torque |
2.5; (Mounting screw) |
| Accessories (optional) |
| Torque wrench:, E70390 | | Flat cable blank:, E70299 |
|
| Pack quantity |
1 pcs. |
