| Application |
Detection of objects on transport equipment |
| Radio approval for |
USA; Canada; EU/RED; Australia; Singapore; China |
| Note on radio approval |
| The list of countries applying the European Radio Equipment Directive 2014/53/EU (RED) can be found under “Downloads”. |
|
| Operating voltage |
26.5...31.6 DC |
| Current consumption |
< 65 |
| Protection class |
III |
| Operating frequency |
0,125 |
| Electrical design |
AS-i |
| Travel speed |
< 0.5 |
| Distance read/read head front |
400 |
| Distance read/read head side |
280 |
| Note on distance read/read head |
| based on | : | | | Read/write antenna | | DTA300 | | Read head | | DTA301 |
|
| Distance write/read head front |
500 |
| Distance write/read head side |
500 |
| Note on distance write/read head |
| based on | : | | | Read/write antenna | | DTA300 | | Read head | | DTA301 |
|
| Distance to the ID tag |
|
| Communication interface |
AS-i |
| Ambient temperature |
-20...60 |
| Storage temperature |
-25...80 |
| Protection |
IP 67 |
| EMC |
|
| Shock resistance |
| EN 60068-2-29 | 40 g 6 ms | | EN 60068-2-27 | 50 g 11 ms |
|
| Vibration resistance |
| EN 60068-2-6 | 20 g 10...55 Hz |
|
| MTTF |
422 |
| AS-i I/O configuration |
7 |
| AS-i ID code |
4 |
| AS-i certificate |
83401 |
| Weight |
414 |
| Housing |
rectangular |
| Dimensions |
92 x 80 x 40 |
| Material |
housing: PPE; metal parts: diecast zinc / brass nickel-plated |
| Display |
| Operating voltage | 1 x LED, green | | tag communication | 1 x LED, yellow | | error in AS-i data communication | 1 x LED, red |
|
| Remarks |
| For the distances to other ID tags see the respective data sheet (E803xx) |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12, rotatable; coding: A |
