| Application |
for up to 4 read/write heads type ANT4xx/ANT5xx/ANT600 |
| Operating voltage |
18...30 DC |
| Current consumption |
< 3000 |
| Number of inputs and outputs |
Number of digital outputs: 4 |
| Number of digital outputs |
4 |
| Max. current load per output |
500; (IO 1,2; IO 3,4: 1000 mA) |
| Communication interface |
Ethernet |
| Factory settings |
| IP address: 192.168.0.79 | | subnet mask: 255.255.255.0 | | gateway IP address: 192.168.0.100 |
|
| Protocol |
PROFINET |
| Ambient temperature |
-20...60 |
| Storage temperature |
-20...85 |
| Protection |
IP 67 |
| Shock resistance |
|
| Vibration resistance |
| IEC 60028-2-6 | ±1.6 mm (17...18 Hz) / 2 g (10...150 Hz) |
|
| MTTF |
108.28 |
| Weight |
393.5 |
| Housing |
rectangular |
| Type of mounting |
Mounting on DIN rail; (TH35 (EN 60715)) |
| Dimensions |
115 x 85 x 46.2 |
| Material |
Upper part: PA Grivory GV5H orange; Upper part: TPE; lower part: GD-AlSi12 |
| Display |
| voltage supply | 1 x LED, green | | 1 x LED, yellow | | PROFINET-IO | 2 x LED, red/green | | Ethernet | 1 x LED, green | | 1 x LED, yellow | | Inputs / outputs | 1 x LED, green | | 1 x LED, yellow |
|
| Items supplied |
| Protective cap: M12, E73004 |
|
| Pack quantity |
1 pcs. |
| Port 1/2 |
Connector: 2 x M12; coding: D |
| IO 1...4 |
Connector: 4 x M12; coding: A |
| AUX |
Connector: 1 x M12; coding: A |
