| Radio approval for |
USA; Canada; EU/RED; Australia; Japan; China; Taiwan; India; Singapore; Ukraine; Brazil |
| Note on radio approval |
| The list of countries applying the European Radio Equipment Directive 2014/53/EU (RED) can be found under “Downloads”. |
|
| Operating voltage |
9...32 DC |
| Current consumption |
< 50 (24 V) / < 80 (12 V) |
| Protection class |
III |
| Operating frequency |
13,56 |
| RFID standard |
ISO 15693 |
| Distance write/read head front |
100 |
| Distance write/read head side |
50 |
| Distance to the ID tag |
|
| Communication interface |
CAN |
| Protocol |
CANopen |
| Ambient temperature |
-40...85 |
| Storage temperature |
-40...85 |
| Protection |
IP 67; IP 69K |
| Shock resistance |
| EN 60068-2-27 | 40 g 6 ms / repetitive | | EN 60068-2-27 | 50 g 11 ms / not repetitive |
|
| Vibration resistance |
| EN 60068-2-6 | 20 g 10...2000 Hz |
|
| MTTF |
475 |
| Weight |
131.5 |
| Housing |
Threaded type |
| Dimensions |
M18 x 1 / L = 70 |
| Thread designation |
M18 x 1 |
| Material |
housing: stainless steel; Protective cover: PPS; LED window: PEI |
| Display |
| Preoperational Mode | 1 x LED, green lights | | Operational Mode | 1 x LED, green flashing | | errors | 1 x LED, red flashing | | tag communication | 1 x LED, yellow lights |
|
| Pack quantity |
1 pcs. |
|
Connector: 1 x M12; coding: A |
