| Application |
Detection of objects on transport equipment |
| Radio approval for |
USA; Canada; EU/RED; Australia; Japan; China; Taiwan; India; Singapore; Ukraine; Malaysia; Brazil; Mexico; Vietnam |
| Note on radio approval |
| The list of countries applying the European Radio Equipment Directive 2014/53/EU (RED) can be found under “Downloads”. |
|
| Operating voltage |
19.2...28.8 DC |
| Current consumption |
< 60 |
| Protection class |
III |
| Operating frequency |
13,56 |
| RFID standard |
ISO 15693 |
| Distance write/read head front |
170 |
| Distance write/read head side |
160 |
| Distance to the ID tag |
| referred to 30 mm coin tag and antenna installed on metal, I-CODE SLI | : | ≤ 32 |
|
| Communication interface |
DATA / DTE10x |
| Ambient temperature |
-20...60 |
| Storage temperature |
-25...80 |
| Protection |
IP 67; IP 69K |
| Shock resistance |
| EN 60068-2-27 | 50 g 11 ms / 40 g (6 ms, continuous) |
|
| Vibration resistance |
| EN 60068-2-6 | 20 g 10...2000 Hz |
|
| MTTF |
457.9 |
| UL approval |
| Ta | -20...60 °C | | Enclosure type | Type 1 | | voltage supply | Limited Voltage/Current | | File number UL | E205959 |
|
| Weight |
80 |
| Housing |
rectangular |
| Mounting |
non-flush mountable |
| Dimensions |
20 x 7 x 48 |
| Material |
PBT; TPE-U; stainless steel |
| Display |
| Power | 1 x LED, green | | tag communication | 1 x LED, yellow |
|
| Pack quantity |
1 pcs. |
|
Cable: 1 m, PUR; 3 x 0.14 mm² |
| Connection |
Connector: 1 x M12; coding: A |
