Фото
Видео
Характеристики
| Operating frequency | 13,56 |
| Communication interface | DATA / DTE10x |
| Dimensions | M30 x 1.5 / L = 50 |
| Product designation | Read/write antenna |
| Radio approval for | USA, Canada, EU/RED, Australia, Japan, China, Taiwan, India, Singapore, Ukraine, South Korea, Brazil, Mexico, Malaysia, New Zealand |
Все характеристики
| Application | Detection of objects on transport equipment | ||||
| Radio approval for | USA; Canada; EU/RED; Australia; Japan; China; Taiwan; India; Singapore; Ukraine; South Korea; Brazil; Mexico; Malaysia; New Zealand | ||||
| Note on radio approval |
|
||||
| Operating voltage | 19.2...28.8 DC; (Supply only via the DTE10x evaluation unit (to EN 60950-1)) | ||||
| Current consumption | < 50 | ||||
| Protection class | III | ||||
| Operating frequency | 13,56 | ||||
| RFID standard | ISO 15693 | ||||
| Distance write/read head front | 100 | ||||
| Distance write/read head side | 50 | ||||
| Distance to the ID tag |
|
||||
| Communication interface | DATA / DTE10x | ||||
| Ambient temperature | -20...60 | ||||
| Storage temperature | -25...80 | ||||
| Protection | IP 67; IP 69K | ||||
| Shock resistance |
|
||||
| Vibration resistance |
|
||||
| MTTF | 556 | ||||
| Weight | 187.5 | ||||
| Housing | Threaded type | ||||
| Mounting | flush mountable | ||||
| Dimensions | M30 x 1.5 / L = 50 | ||||
| Thread designation | M30 x 1.5 | ||||
| Material | housing: stainless steel; Protective cover: PPS | ||||
| Display |
|
||||
| Items supplied |
|
||||
| Pack quantity | 1 pcs. | ||||
| Connection | Connector: 1 x M12; coding: A |
Приемущества
| For the reliable identification of ID tags on workpiece carriers and products |
| Robust stainless steel housing for applications in mounting, feeding and handling technology |
| Suitable for use with RFID antenna adapters to increase the ranges |
| RFID read/write head HF for flush mounting |
| For the connection to RFID evaluation units LF/HF using the tried-and-tested M12 connection |
