| Application |
| for use with GSDML files of ifm IO-Link masters type AL14xx, AL130x, AL1901 |
|
| Configuration |
|
| Compatibility |
| compatible with GSDML files of the AL14xx, AL130x series, the AL1901 and all IO-Link devices |
|
| Data management |
| integration of IO-Link device parameters into the selected GSDML file |
|
| Parameter setting |
| writing selected device parameters into a subslot of the GSDML file | | display of already integrated IO-Link devices |
|
| User interface |
| the user interface is integrated into the dashboard function of moneo configure (SA) | | display of all integrations already effected and of the current action | | indication of available memory and allocated memory, per subslot | | indication of currently selected parameters |
|
| IO-Link functions |
| user-specific selection of the required IO-Link parameters to be integrated |
|
| Language |
German; English; French; Italian; Spanish; Portuguese; Chinese; Japanese; Korean; Polish |
| Data carrier |
download |
| Type of license |
single license |
| License class |
on-premises full version |
| Min. CPU cycle |
2,3 GHz |
| Min. number of CPU cores |
4 |
| Min. RAM |
8 GB |
| Min. graphic resolution |
1920 x 1080 |
| Required device interface |
USB; LAN Adapter - RJ45 |
| Network card |
Ethernet 1 Gbit |
| Network protocol |
Ethernet TCP/IP |
| Operating system |
Microsoft Windows 10 64 Bit; Microsoft Windows Server 2016; Microsoft Windows Server 2019; Microsoft Windows Server 20H2 |
| Web browser |
Google Chrome; Mozilla Firefox; (supported versions: see current release notes) |
| Additionally required software |
|
