| Application |
Sensor data collected and sent to the ifm cloud via radio transmission |
| Radio approval for |
USA; Canada; EU/RED; Australia; Japan; South Africa; Malaysia; Israel |
| Note on radio approval |
| The list of countries applying the European Radio Equipment Directive 2014/53/EU (RED) can be found under “Downloads”. |
|
| Operating voltage |
18...30 DC |
| Current consumption |
< 2000 |
| Power consumption |
8.6 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Current rating per port |
0.5; (IO-Link port) |
| Transmission standard |
BLE 5.0 |
| Frequency band |
2402...2480 MHz |
| Transmission power |
2.51 |
| Usage type |
service interface |
| Note on interfaces |
| ceramic antenna integrated |
|
| Number of inputs and outputs |
Number of digital outputs: 2 |
| Number of digital outputs |
2 |
| Max. current load per output |
200 |
| Parameter setting options |
dashboard display with alarm functions via email or text message |
| Communication interface |
IO-Link; Mobile networks; Bluetooth |
| Number of ports |
2 |
| Unterstützte IO-Link Revision |
1.0; 1.1 |
| Transmission type |
COM1 (4,8 kBaud); COM2 (38,4 kBaud); COM3 (230,4 kBaud) |
| Transmission standard |
NarrowBand-IoT; 2G quadband GSM; LTE Cat-M1 |
| Frequency band |
B1(2100); B2(1900); B3(1800); B4(AWS1700); B5(850); B8(900); B12(700); B18(800); B19(800); B20(800); B26(850); B28(700) |
| Ambient temperature |
-20...50 |
| Storage temperature |
-40...60 |
| Max. height above sea level |
3000 |
| Protection |
IP 65 |
| EMC |
| EN 301489-1 | | | EN 301489-17 | | | EN 301489-52 | |
|
| Vibration resistance |
|
| Shock resistance |
|
| Radio approval |
EN 301511
EN 301908-1
EN 301908-13
EN 300328 |
| Weight |
152.6 |
| Housing |
rectangular |
| Dimensions |
97.4 x 113 x 32.5 |
| Material |
housing: ABS |
| Display |
| voltage supply | 1 x LED, yellow | | communication | 1 x LED | | IO-Link port | 2 x LED, green |
|
| Remarks |
|
| Pack quantity |
1 pcs. |
| IO-Link Port 1 |
Connector: 2 x M12; coding: A |
| Power |
Connector: 1 x M12; coding: A |
