| Application |
| IT hardware to operate production-related software | | providing memory capacity and processing power | | Easy set-up without requiring special IT knowledge |
|
| Compatibility |
| can be used independent of IT infrastructure | | can be integrated in IT network structure at any time |
|
| Connectivity |
| interfaces for sensor and IT network |
|
| Operating voltage |
10...36 DC |
| Power consumption |
21; (maximum: 47) |
| Number of video outputs |
2; (DisplayPort) |
| Note on license |
hardware bound; software must be ordered and installed separately for operation |
| Communication interface |
Ethernet; RS232; USB |
| Number of Ethernet interfaces |
3; (GBit) |
| Number of R232 interfaces |
4; (RS232/RS422/RS485) |
| Number of USB interfaces |
4; (3 x USB 3.2 Gen1; 1 x USB 2.0 Type A) |
| Ambient temperature |
0...70 |
| Storage temperature |
-20...60 |
| Max. relative air humidity |
95; (40 °C non condensing) |
| Protection |
IP 40 |
| Shock resistance |
|
| Vibration resistance |
| IEC 60068-2-64 | 4 Grms / 5...500 Hz |
|
| Weight |
2185.1 |
| Dimensions |
45 x 140 x 200 |
| Processor |
Intel Core i5-1145G7E quad-core |
| TPM chip |
V 2.0 |
| BIOS |
AMI UEFI (256 Mbit) |
| Working memory |
16 GB |
| Mass storage |
1 TB SSD |
| Items supplied |
|
| Notes |
the required licenses to operate software products must be ordered separately |
| Pack quantity |
1 pcs. |
