| System |
Halogen-free; gold-plated contacts |
| Application |
signaling machine conditions |
| Operating voltage |
21.6...26.4 DC |
| Nominal voltage DC |
24; (to SELV/PELV) |
| Max. current consumption |
360; (red: 80; green: 80; blue: 80; white: 120) |
| Color temperature |
7500 |
| Luminous flux |
red: 184.96; green: 572; blue: 116; white: 768.32 |
| Note on luminous flux |
| luminous flux indications refer to one meter of LED strip |
|
| Typ. lifetime |
38000 |
| Input circuit of digital inputs |
24 V PNP |
| Ambient temperature |
-20...45 |
| Max. relative air humidity |
90 |
| Max. height above sea level |
4000 |
| Protection |
IP 68 |
| Degree of soiling |
2 |
| Approval |
EN 62471; IEC 62031 |
| Weight |
53.1 |
| Dimensions |
265 x 14.2 x 4.5 |
| Material |
housing: TPU (urethane) |
| Sealing material |
FKM |
| Display |
| signaling machine conditions | LED, multi-color RGB | | mounting light | LED, white |
|
| Pack quantity |
1 pcs. |
|
Connector: M12, angled; coding: A; Moulded body: TPU (urethane), orange; Locking: brass, nickel-plated; sealing: FKM; Contacts: gold-plated; Tightening torque: 0.6...1.5 Nm |
