| Type of light |
Infrared light |
| System |
gold-plated contacts |
| Illuminated field |
50 x 50 |
| Design |
backlight |
| Type of operation |
Permanent light or pulse operation |
| Operating voltage tolerance |
-10...10 |
| Operating voltage |
24 DC |
| Current consumption |
< 325 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Type of light |
Infrared light |
| Wave length |
875 |
| Trigger |
5...24 V |
| Ambient temperature |
-10...50 |
| Protection |
IP 54 |
| Overheat protection |
yes; (> 50 °C) |
| Photobiological safety |
exempt group; (EN 62471) |
| MTTF |
309 |
| Weight |
264.4 |
| Dimensions |
105 x 81 x 9.8 |
| Material |
aluminum |
| Lens material |
|
| Display |
| Illumination status | 1 x LED, yellow | | Power | 1 x LED, green | | Excess temperature / overload | 1 x LED, red |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; coding: A; Contacts: gold-plated |
