| Type of light |
White light; Infrared light |
| Illuminated field |
130 x 130 |
| Design |
Dome |
| Type of operation |
normal light intensity (permanent operation possible); High light intensity (pulsed) |
| Operating voltage |
24 DC |
| Current consumption |
Operating mode "permanent operation": 540; operating mode "high light intensity": 2580 |
| Protection class |
III; (PELV) |
| Type of light |
White light; Infrared light |
| Number of inputs and outputs |
Number of digital inputs: 1 |
| Trigger |
24 V PNP/NPN; external |
| Number of digital inputs |
1 |
| Ambient temperature |
-10...40 |
| Storage temperature |
-20...60 |
| Protection |
IP 65 |
| Photobiological safety |
risk group 1; (DIN EN 62471) |
| Weight |
1018.15 |
| Dimensions |
256.8 x 197 x 106.8 |
| Material |
housing: aluminum black anodized; Cover: ABS |
| Tightening torque |
0.5...1.5 |
| Display |
| Power | 1 x LED, green | | operating mode "high light intensity" | 1 x LED, red | | LED segment | 1 x LED, white |
|
| Pack quantity |
1 pcs. |
|
Connector: M12; coding: A |
|
Connector: M12; coding: A |
