| Type of light |
White light |
| Illuminated field |
10 x 75 |
| Design |
bar |
| Type of operation |
high light intensity (pulsed, permanent operation with cooling only); normal light intensity (permanent operation possible) |
| Operating voltage |
24 DC |
| Current consumption |
Operating mode "permanent operation": 165; operating mode "high light intensity": 275 |
| Type of light |
White light |
| Color temperature |
5600 |
| Trigger |
24 V PNP |
| Ambient temperature |
-10...55 |
| Storage temperature |
-25...75 |
| Protection |
IP 65 |
| Overheat protection |
yes; (deactivation at 65...75 °C) |
| Photobiological safety |
exempt group; (DIN EN 62471:2008) |
| Weight |
180.5 |
| Dimensions |
116 x 13 x 18 |
| Material |
aluminum black anodized |
| Lens material |
|
| Display |
| Illumination status | 1 x LED, yellow | | Power | 1 x LED, green | | Excess temperature | 1 x LED, red |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; coding: A |
