| Type of light |
red light |
| Illuminated field |
Ø 106 / Ø 66; (external / internal) |
| Design |
ring |
| Type of operation |
high light intensity (pulsed, permanent operation with cooling only); normal light intensity (permanent operation possible) |
| Operating voltage |
24 DC |
| Current consumption |
Operating mode "permanent operation": 800; operating mode "high light intensity": 1300 |
| Type of light |
red light |
| Wave length |
617 |
| Trigger |
24 V PNP |
| Angle of aperture cylindrical |
60 |
| Ambient temperature |
-10...55 |
| Storage temperature |
-25...75 |
| Protection |
IP 65 |
| Overheat protection |
yes; (deactivation at 65...75 °C) |
| Photobiological safety |
exempt group; (DIN EN 62471:2008) |
| Weight |
491.5 |
| Dimensions |
Ø 122 / L = 20.5 |
| Material |
aluminum black anodized |
| Lens material |
|
| Display |
| Combined LED, three-color | | Illumination status | yellow | | Power | green | | Excess temperature | red |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; coding: A |
