| System |
Free from silicone; gold-plated contacts |
| Free from silicone |
yes |
| Operating voltage |
< 60 AC/DC; (cULus: 30 AC / 42 DC) |
| Protection class |
II |
| Max. current load per module/slot |
4 |
| Max. current load total |
4 |
| Overall current rating (UL) |
3 |
| Ambient temperature |
-25...90 |
| Note on ambient temperature |
|
| Storage temperature |
-25...55 |
| Storage humidity |
10...100 |
| Other climatic conditions for storage according to stated class |
|
| Protection |
IP 65; IP 67; IP 68; IP 69K |
| Weight |
36.8 |
| Material |
housing: PA orange; sealing: FKM |
| Material nut |
brass, nickel-plated |
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; coding: A; Locking: brass, nickel-plated; Contacts: gold-plated; Tightening torque: 0.6...1.5 Nm |
|
Connector: 2 x M12; coding: A; Locking: brass, nickel-plated; Contacts: gold-plated; Tightening torque: 0.6...1.5 Nm |
