| System |
Free from silicone; gold-plated contacts |
| Free from silicone |
yes |
| Operating voltage |
< 50 AC / < 60 DC; (cULus: 30 AC / 42 DC) |
| Protection class |
III |
| Max. current load total |
3 |
| Ambient temperature |
-25...90 |
| Note on ambient temperature |
|
| Protection |
IP 65; IP 67; IP 68; IP 69K |
| UL approval |
| voltage supply | Class 2 | | File number UL | E191684 |
|
| Weight |
30.2 |
| Material |
housing: PA orange |
| Material nut |
brass, nickel-plated |
| Sealing material |
FKM |
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; coding: A; Locking: brass, nickel-plated; Contacts: gold-plated; Tightening torque: 0.6...1.5 Nm |
|
Connector: 2 x M8; coding: A; Locking: brass, nickel-plated; sealing: FKM; Contacts: gold-plated; Tightening torque: 0.3...0.5 Nm |
