| Connection | M12 Connector |
| Product designation | H splitter |
| Ambient temperature | -40...85 |
Все характеристики
| System | gold-plated contacts | |
| Operating voltage | < 63 DC | |
| Protection class | III | |
| Max. current load total | 16; (40 °C) | |
| Ambient temperature | -40...85 | |
| Protection | IP 65 | |
| Weight | 130.7 | |
| Material | housing: PBT black | |
| Material nut | brass, nickel-plated | |
| Sealing material | HNBR | |
| Items supplied |
|
|
| Pack quantity | 1 pcs. | |
| Connector: 3 x M12; coding: L; Locking: brass, nickel-plated; sealing: HNBR; Contacts: gold-plated | ||
| Connection | Connector: 1 x M12; coding: L; Locking: brass, nickel-plated; Contacts: gold-plated |
Приемущества
| Large cable cross-section for reducing the voltage drop and transferring higher currents |
| Resistant to oils and coolants |
| Permanent, reliable sealing even when mounted without tools |
