| System |
gold-plated contacts |
| Operating voltage |
15...30 DC; (cULus - Class 2 source required) |
| Protection class |
III |
| Max. current load per module/slot |
2 |
| Max. current load total |
2 |
| Electrical design |
PNP |
| Ambient temperature |
-25...80 |
| Ambient temperature (moving) |
-5...60 |
| Protection |
IP 67; IP 68; (1 m / 7 days) |
| Weight |
128.5 |
| Housing |
rectangular |
| Type of mounting |
Backplane mounting |
| Dimensions |
129.5 x 30 x 28.8 |
| Material |
PBT-GF20 |
| Material nut |
brass, nickel-plated |
| Number of ports splitter box |
8 |
| Connector type |
M8 |
| Display |
| Switching status | 8 x LED, yellow | | Power | 1 x LED, green |
|
| Accessories (optional) |
| Protective cap: M8, E73005 |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; Locking: brass, nickel-plated; Contacts: gold-plated; Tightening torque: 0.8...1.5 Nm |
|
Connector: 8 x M8; coding: A; Locking: brass, nickel-plated; Contacts: gold-plated; Tightening torque: 0.8...1.5 Nm |
