| System |
gold-plated contacts |
| Operating voltage |
15...30 DC |
| Protection class |
III |
| Max. current load per module/slot |
1 |
| Max. current load total |
1 |
| Electrical design |
PNP |
| Ambient temperature |
-25...80 |
| Ambient temperature (moving) |
-5...60 |
| Protection |
IP 67 |
| Weight |
125 |
| Housing |
rectangular |
| Type of mounting |
Backplane mounting |
| Dimensions |
129.5 x 30 x 28.8 |
| Material |
housing: PBT-GF20 |
| Material nut |
brass, nickel-plated |
| Number of ports splitter box |
8 |
| Connector type |
M8 |
| Display |
| Switching status | 8 x LED, yellow | | Power | 1 x LED, green |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12; Locking: brass, nickel-plated; Contacts: gold-plated; Tightening torque: 0.8...1.5 Nm |
|
Connector: 8 x M8; coding: A; Locking: brass, nickel-plated; Contacts: gold-plated; Tightening torque: 0.8...1.5 Nm |
