| System |
Free from silicone; Halogen-free; gold-plated contacts; Drag chain suitability |
| Free from silicone |
yes |
| Operating voltage |
< 30 AC/DC; (cULus - Class 2 source required) |
| Protection class |
II |
| Max. current load per module/slot |
4 |
| Max. current load total |
12 |
| Ambient temperature |
-25...80 |
| Ambient temperature (moving) |
-5...60 |
| Protection |
IP 67; IP 68 |
| UL approval |
|
| Weight |
1470.5 |
| Housing |
rectangular |
| Type of mounting |
Backplane mounting |
| Dimensions |
100 x 54 x 22 |
| Material |
housing: PA |
| Material nut |
brass, nickel-plated |
| Number of ports splitter box |
6 |
| Connector type |
M12 |
| Drag chain suitability |
| Bending radius for flexible applications | min. 10 x cable diameter | | Bending cycles | > 2 Mio. |
|
| Items supplied |
| Protective caps: 2 | | labels: 6 |
|
| Pack quantity |
1 pcs. |
|
Connector: 1 x M23, angled; Locking: brass, nickel-plated; Contacts: gold-plated; Tightening torque: 0.8...1.5 Nm |
| Connection |
Cable: 10 m, PUR, Halogen-free, black, Ø 8.8 mm; 12 x 0.34 mm² (63 x Ø 0.1 mm ) + 3 x 1.0 mm² (127 x Ø 0.1 mm ) |
|
Connector: 6 x M12; coding: A; Locking: brass, nickel-plated; Contacts: gold-plated; Tightening torque: 0.8...1.5 Nm |
