| System |
Free from silicone; gold-plated contacts; Drag chain suitability |
| Application |
sanitary and wet areas in the food industry |
| Free from silicone |
yes |
| Operating voltage |
< 50 AC / < 60 DC |
| Protection class |
III |
| Max. current load total |
3 |
| Ambient temperature |
-25...80 |
| Note on ambient temperature |
|
| Ambient temperature (moving) |
5...80 |
| Note on ambient temperature (moving) |
|
| Protection |
IP 65; IP 67; IP 68; IP 69K |
| Weight |
73 |
| Molded-body material |
PVC |
| Material nut |
stainless steel (1.4404 / 316L) |
| Sealing material |
EPDM |
| Number of ports splitter box |
2 |
| Drag chain suitability |
| Bending radius for flexible applications | min. 10 x cable diameter | | Travel speed | max. 3.3 m/s for a horizontal travel length of 5 m and max. acceleration of 5 m/s² | | Bending cycles | > 1 Mio. | | Torsional strain | ± 180 °/m |
|
| Pack quantity |
1 pcs. |
| Connection |
Connector: 1 x M12, straight; coding: A; Moulded body: PVC, orange; Locking: stainless steel (1.4404 / 316L); Contacts: gold-plated; Tightening torque: 0.6...1.5 Nm |
|
Connector: 2 x M8, angled; coding: A; Moulded body: PVC, orange; Locking: stainless steel (1.4404 / 316L); sealing: EPDM; Contacts: gold-plated; Tightening torque: 0.3...0.5 Nm |
