| Frequency band |
1575,42...1610 MHz |
| Type of connector |
SMA |
| Note on interfaces |
| Operating voltage: 3...5 V DC | | Current consumption: < 15 mA | | Impedance: 50 Ohm | | Polarization: RHCP | | LNA: 28 ± 2 dB | | LNA V.S.W.R.: < 2,0 | | noise density: < 1,5 dB |
|
| Transmission standard |
LTE Cat-4 |
| Frequency band |
LTE: 698...960 MHz; 1710...2690 MHz |
| Type of connector |
SMA |
| Note on interfaces |
| Impedance: 50 Ohm | | Polarization: linear vertical | |
|
| Frequency band |
2400...2483,5 MHz; 4900...5825 MHz |
| Type of connector |
SMA |
| Note on interfaces |
| Impedance: 50 Ohm | | Polarization: linear | | noise density: 2 dBi | |
|
| Ambient temperature |
-40...85 |
| Protection |
IP 67 |
| Weight |
597.5 |
| Type of mounting |
screw mounting |
| Dimensions |
Ø 110 / L = 55 |
| Material |
ABS |
| Pack quantity |
1 pcs. |
|
Connector: 1 x SMA |
|
Connector: 2 x SMA |
|
Connector: 2 x SMA |
