| Frequency band |
2400...2480 MHz (802.11b/g/n); 5150...5852 MHz (802.11a/h/j/n/ac) |
| Type of connector |
FAKRA |
| Note on interfaces |
| VSWR: < 2,0 | | Antenna gain (2,4 GHz): + 3 dBi | | Antenna gain (5,3 GHz): + 1 dBi | | Power: < 10 W |
|
| Ambient temperature |
-40...85 |
| Protection |
IP 69K |
| Standard |
IEC 60068-2-14 Nb; IEC 60068-2-14 Na; IEC 60068-2-3 Db; IEC 60068-2-2; IEC 60068-2-27; ISO 16750-2; EN 45545-2; ECE R 118 |
| Weight |
105.85 |
| Type of mounting |
screw mounting; (M16 x 1,5) |
| Dimensions |
Ø 76 / L = 23 |
| Tightening torque |
5 |
| Remarks |
| When mounting the antenna(s) in vehicles avoid the vicinity of fuel tanks, vessels with explosives or insufficiently screened electronic components. | | Do not install antenna inside closed metal construction (e.g. in driver's cabin). | | Clean the mounting surface before the installation. | | Do not extend or shorten antenna cable. | | Avoid direct exposure to steam or high-pressure cleaning during car wash. | | Radio communication can affect the function of electronic devices that are not correctly shielded. | | Contact the manufacturer of the corresponding device in case of any interference. |
|
| Pack quantity |
1 pcs. |
|
Connector: FAKRA I |
